TECNA 9321ES ESD Protection Retractor Balancer
Cable Type: Stainless Steel
Zero-Gravity: No
Explosion Resistant - ATEX-Rated Hazardous: No
Capacity: 4.0 - 9.0 lbs. / 2.0 - 4.0 kg
Stroke Length: 79 in. / 2000 mm
The 9321ES ESD protection retractor balancer is a NEW product line designed for electronics assembly and ESD-protected applications. The 9321ES features an aluminum housing, stainless steel cable, and anti-electrostatic materials with a capacity of 4.41 - 8.82 lbs. (2.0 - 4.0 kg.) and a stroke length of 78.74 in. (2000 mm).
| Cable Type | Stainless Steel |
|---|---|
| Body / Housing Material | Aluminum |
| Zero-Gravity Tool Balancer | No |
| Lower Capacity (lbs. / kg) | 4.0 / 2.0 |
| Upper Capacity (lbs. / kg) | 9.0 / 4.0 |
| Stroke Length (in. / mm) | 79 / 2000 |
| Explosion Resistant - ATEX-Rated Hazardous | No |
| ATEX Class | -- |
| INCLUDES Option "F" - Brake / Friction Device | No |
| INCLUDES Option "RI" - Rotary and Insulating Device | No |
| INCLUDES Option "B" - Floor Locking / Unlocking Device | No |
- Certification for ESD-PROTECTED AREAS (EPA)
- Anti-electrostatic materials
- Grounded
- Rugged construction, cast aluminium body
- Stainless steel rope
- Adjustable capacity
- Safety suspension
- Safety device against load dropping due to the spring breakage (>3kg)
- Adjustable stroke limiting device
- Cable guide in antifriction material
- Inert spring drum assembly
- Polyamides thimble
- Operating temperature between + 5°C to + 60°C
* Features may vary, and are subject to change without notice. Please contact your TECNA representative to request a quote.
Available for certain models, please contact a customer service representative for help selecting the right product for your application.
OPTION ".F" version is equipped with a friction / brake which controls the rotation speed of the drum.
Balancers models 9346LES - 9350ES are equipped with a stop device allowing to stop the load in intermediate positions of the stroke, about every 3.94 in. (100 mm). The stop device can be activated and deactivated at the operator's choice.
TECNA recommends OPTIONAL ACCESSORY "RC" - Rotary and insulating device for ESD zero-gravity balancers.
OPTIONAL ACCESSORY "BC" - Locking-unlocking device with control from the floor.
TECNA Stainless Steel Cable Balancers FOR SALE | BUY NOW
TECNA Stainless Steel Cable Balancers from BALANCERSDirect.com are a multifunctional and durable spring / tool balancer, featuring a nylon, aluminum or rubberized-aluminum body material. Furthermore, they carry the load on a stainless steel wire rope. TECNA balancers make tools nearly weightless, reducing operator fatigue and improving safety and ergonomics. As the tool is repositioned the stainless steel cable extends and retracts smoothly from the aluminum housing, providing full range of motion. Tension adjustment is easy and precise.
Find TECNA retractors and zero-gravity tool balancers FOR SALE at Weld Systems Integrators. We keep an inventory of TECNA tool balancers IN-STOCK at our Warrensville Heights, OHIO location. Our current inventory of TECNA retractors and zero-gravity tool balancers includes:
- Air hose retractors
- Bowden retractors
- ESD-protected (electrostatic discharge) retractors and zero-gravity balancers
- Explosion-resistant (ATEX-rated) retractors and zero-gravity balancers
- Food industry retractors and zero-gravity balancers
- Standard stainless steel cable retractors and zero-gravity balancers
- Synthetic cable (Polypropylene and Dyneema) retractors
For immediate assistance, call 844-44-TECNA or 216-475-5629. You can also order online | BUY NOW.
