TECNA 9346IL Food Industry Retractor Balancer

Cable Type:  Stainless Steel
Zero-Gravity:  No
Explosion Resistant - ATEX-Rated Hazardous:  No
Capacity:  4.4 - 8.8 lbs. / 2.0 - 4.0 kg
Stroke Length:  98 in. / 2500 mm

The TECNA 9346IL food industry balancer is a NEW product line designed for food and beverage, meat processing, dairy, bakery and confectionery, and industrial washing and sanitizing applications. The 9346IL features an aluminum housing with hard anodizing treatment, NSF-H1 certified food grade grease, rust-proof stainless steel wire rope with a capacity of 4.4 - 8.8 lbs. (2.0 - 4.0 kg) and a stroke length of 98.4 in. (2500 mm).

These balancers are equipped with a stop device allowing the load to stop in intermediate positions of the stroke, about every 3.94 in. (100 mm). The stop device can be activated and deactivated at the operator's choice.

Cable Type Stainless Steel
Body / Housing Material Aluminum with Hard Anodizing Treatment
Zero-Gravity Tool Balancer No
Lower Capacity (lbs. / kg) 4.4 / 2.0
Upper Capacity (lbs. / kg) 8.8 / 4.0
Stroke Length (in. / mm) 98 / 2500
Explosion Resistant - ATEX-Rated Hazardous No
ATEX Class --
INCLUDES Option "F" - Brake / Friction Device No
INCLUDES Option "RI" - Rotary and Insulating Device No
INCLUDES Option "B" - Floor Locking / Unlocking Device No
  • Cast aluminium housing with special hard anodization, resistant to oxidation and chemical aggression
  • NSF-H1 certified Food Grade grease
  • Rust-proof stainless steel materials on all external parts
  • Rugged construction, cast aluminium housing with hard anodization, resistant to oxidation and chemical aggression
  • Stainless steel rope
  • Adjustable capacity
  • Auxiliary safety suspension
  • Adjustable stroke limiting device
  • Cable guide in antifriction material
  • Inert spring drum assembly
  • Polyamides thimble

* Features may vary, and are subject to change without notice. Please contact your TECNA representative to request a quote.

Available for certain models, please contact a customer service representative for help selecting the right product for your application.

Balancers models 9346LIL - 9350IL are equipped with a stop device allowing to stop the load in intermediate positions of the stroke, about every 3.94 in. (100 mm). The stop device can be activated and deactivated at the operator's choice.

OPTIONAL ACCESSORY "B1" - Locking-unlocking device with control from the floor (chain and handle in stainless steel). Available for balancer models:

  • 9502RL - 9509RL
  • 9520RL - 9525RL


TECNA Stainless Steel Cable Balancers FOR SALE and IN-STOCK from BALANCERSDirect.com

TECNA Stainless Steel Cable Balancers from BALANCERSDirect.com are a multifunctional and durable spring / tool balancer, featuring a nylon, aluminum or rubberized-aluminum body material. Furthermore, they carry the load on a stainless steel wire rope. TECNA balancers make tools nearly weightless, reducing operator fatigue and improving safety and ergonomics. As the tool is repositioned the stainless steel cable extends and retracts smoothly from the aluminum housing, providing full range of motion. Tension adjustment is easy and precise.

Most TECNA Stainless Steel Cable Balancers are also available in Explosion Resistant (ATEX-Rated) and Nylon Cable (synthetic rope) models. Optional Rubber Guards may also be available.

BALANCERSDirect.com, powered by Weld Systems Integrators, Inc. (WSI), is a stocking master distributor of TECNA spring tool balancers and tool retractors. We maintain an IN-STOCK inventory FOR SALE at our Warrensville Heights, Ohio location for quick shipment and delivery.

For immediate assistance, call at 844-44-TECNA or +1-216-475-5629. You can also complete our FREE online BALANCER QUOTE form.
